LED光圈款

常规款

/

电源:AC100-240V,50/60Hz

额定功率:600W

灯泡型号:380W

光通量为7950lm,色温可达8500K

出光口径:152mm

镇流器:电子电感镇流器

控制方式:DMX512/声控/自走/RDM

通道:16/18通道

漂亮的点阵显示,四个轻触开关,可倒转180°显示

颜色盘:一个颜色盘,每个颜色盘由14个色片组成+白色,旋转速度可调,双向流水效果及彩虹效果。

图案盘:固定图案盘,14个图案效果+白光

棱镜:48蜂窝棱镜,12棱镜,双棱镜可叠加

双向旋转,旋转速度可调。

调焦:线性调焦,由近至远。

具有雾化功能

0—100%机械调光,支持机械频闪和可调速频闪效果,支持频闪宏功能,机械频闪为1-12 F.P.S。

一个颜色盘,每个颜色盘由14个色片组成+白色,旋转速度可调,双向流水效果及彩虹效果°

采用光电复位系统,当偶然发生误动后,可自动检索复位

水平540°,8Bit/16Bit微调

垂直270°,8Bit/16Bit微调

具有水平、垂直精细自动纠错功能。

过热保护:IP防护等级:IP20

开关电源。液晶显示屏。

Power supply: AC100-240V, 50/60Hz

Rated power: 600W

Light bulb model: 380W

The luminous flux is 7950lm and the color temperature can reach 8500K

Aperture: 152mm

Ballast: electronic inductor ballast

Control mode: DMX512/voice control/self-propelled/RDM

Channel: 16/18 channels

Beautiful dot matrix display with four touch switches that can be reversed 180 ° for display

Color palette: One color palette, each consisting of 14 color chips+white, adjustable rotation speed, bidirectional flowing effect and rainbow effect.

Pattern plate: Fixed pattern plate, 14 pattern effects+white light

Prism: 48 honeycomb prism, 12 prism, dual prism can be stacked

Bidirectional rotation, adjustable rotation speed.

Focusing: Linear focusing, from near to far.

Equipped with atomization function

0-100% mechanical dimming, supports mechanical strobe and adjustable strobe effects, supports strobe macro function, mechanical strobe is 1-12 F.P.S.

A color palette, each consisting of 14 color chips+white, with adjustable rotation speed, bidirectional flowing effect and rainbow effect

Adopting a photoelectric reset system, the reset can be automatically retrieved in case of accidental misoperation

Horizontal 540 °, 8Bit/16Bit fine-tuning

Vertical 270 °, 8Bit/16Bit fine-tuning

It has horizontal and vertical fine automatic error correction functions.

Overheating protection: IP protection level: IP20

Switching power supply. LCD display screen.

说明书:

新款380W光束+LED光圈说明书-中文.doc

NEW380WMOVING HEAD BEAM+LED(1).docx
